CHEMICAL EXAMINATION OF URINE
The chemical examination is carried out for substances in urine are listed below:
- Bile salts
- Nitrite or leukocyte esterase
Normally, kidneys excrete scant amount of protein in urine (up to 150 mg/24 hours). These proteins include proteins from plasma (albumin) and proteins derived from urinary tract (Tamm-Horsfall protein, secretory IgA, and proteins from tubular epithelial cells, leucocytes, and other desquamated cells); this amount of proteinuria cannot be detected by routine tests.
(Tamm-Horsfall protein is a normal mucoprotein secreted by ascending limb of the loop of Henle).
Proteinuria refers to protein excretion in urine greater than 150 mg/24 hours in adults.
Causes of Proteinuria
Causes of proteinuria can be grouped as shown in Box 826.1.
- Glomerular proteinuria: Proteinuria due to increased permeability of glomerular capillary wall is called as glomerular proteinuria.
There are two types of glomerular proteinuria: selective and nonselective. In early stages of glomerular disease, there is increased excretion of lower molecular weight proteins like albumin and transferrin. When glomeruli can retain larger molecular weight proteins but allow passage of comparatively lower molecular weight proteins, the proteinuria is called as selective. With further glomerular damage, this selectivity is lost and larger molecular weight proteins (γ globulins) are also excreted along with albumin; this is called as nonselective proteinuria.
Selective and nonselective proteinuria can be distinguished by urine protein electrophoresis. In selective proteinuria, albumin and transferrin bands are seen, while in nonselective type, the pattern resembles that of serum (Figure 826.1).
Causes of glomerular proteinuria are glomerular diseases that cause increased permeability of glomerular basement membrane. The degree of glomerular proteinuria correlates with severity of disease and prognosis. Serial estimations of urinary protein are also helpful in monitoring response to treatment. Most severe degree of proteinuria occurs in nephrotic syndrome (Box 826.2).
- Tubular proteinuria: Normally, glomerular membrane, although impermeable to high molecular weight proteins, allows ready passage to low molecular weight proteins like β2-microglobulin, retinol-binding protein, lysozyme, α1-microglobulin, and free immunoglobulin light chains. These low molecular weight proteins are actively reabsorbed by proximal renal tubules. In diseases involving mainly tubules, these proteins are excreted in urine while albumin excretion is minimal.
Urine electrophoresis shows prominent α- and β-bands (where low molecular weight proteins migrate) and a faint albumin band (Figure 826.1).
Tubular type of proteinuria is commonly seen in acute and chronic pyelonephritis, heavy metal poisoning, tuberculosis of kidney, interstitial nephritis, cystinosis, Fanconi syndrome and rejection of kidney transplant.
Purely tubular proteinuria cannot be detected by reagent strip test (which is sensitive to albumin), but heat and acetic acid test and sulphosalicylic acid test are positive.
- Overflow proteinuria: When concentration of a low molecular weight protein rises in plasma, it “overflows” from plasma into the urine. Such proteins are immunoglobulin light chains or Bence Jones proteins (plasma cell dyscrasias), hemoglobin (intravascular hemolysis), myoglobin (skeletal muscle trauma), and lysozyme (acute myeloid leukemia type M4 or M5).
- Hemodynamic proteinuria: Alteration of blood flow through the glomeruli causes increased filtration of proteins. Protein excretion, however, is transient. It is seen in high fever, hypertension, heavy exercise, congestive cardiac failure, seizures, and exposure to cold.
Postural (orthostatic) proteinuria occurs when the subject is standing or ambulatory, but is absent in recumbent position. It is common in adolescents (3-5%) and is probably due to lordotic posture that causes inferior venacaval compression between the liver and vertebral column. The condition disappears in adulthood. Amount of proteinuria is <1000 mg/day. First-morning urine after rising is negative for proteins, while another urine sample collected after patient performs normal activities is positive for proteins. In such patients, periodic testing for proteinuria should be done to rule out renal disease.
- Post-renal proteinuria: This is caused by inflammatory or neoplastic conditions in renal pelvis, ureter, bladder, prostate, or urethra.
Further reading: Tests for Detection of Proteinuria
The main indication for testing for glucose in urine is detection of unsuspected diabetes mellitus or follow-up of known diabetic patients.
Practically all of the glucose filtered by the glomeruli is reabsorbed by the proximal renal tubules and returned to circulation. Normally a very small amount of glucose is excreted in urine (< 500 mg/24 hours or <15 mg/dl) that cannot be detected by the routine tests. Presence of detectable amounts of glucose in urine is called as glucosuria or glycosuria (Box 826.3). Glycosuria results if the filtered glucose load exceeds the capacity of renal tubular reabsorption. Most common cause is hyperglycemia from diabetes mellitus.
Causes of Glycosuria
1. Glycosuria with hyperglycemia:
- Endocrine diseases: diabetes mellitus, acromegaly, Cushing’s syndrome, hyperthyroidism, pancreatic disease
- Non-endocrine diseases: central nervous system diseases, liver disorders
- Drugs: adrenocorticotrophic hormone, corticosteroids, thiazides
- Alimentary glycosuria (Lag-storage glycosuria): After a meal, there is rapid intestinal absorption of glucose leading to transient elevation of blood glucose above renal threshold. This can occur in persons with gastrectomy or gastrojejunostomy and in hyperthyroidism. Glucose tolerance test reveals a peak at 1 hour above renal threshold (which causes glycosuria); the fasting and 2-hour glucose values are normal.
2. Glycosuria without hyperglycemia
- Renal glycosuria: This accounts for 5% of cases of glycosuria in general population. Renal threshold is the highest glucose level in blood at which glucose appears in urine and which is detectable by routine laboratory tests. The normal renal threshold for glucose is 180 mg/dl. Threshold substances need a carrier to transport them from tubular lumen to blood. When the carrier is saturated, the threshold is reached and the substance is excreted. Up to this level glucose filtered by the glomeruli is efficiently reabsorbed by tubules. Renal glycosuria is a benign condition in which renal threshold is set below 180 mgs/dl but glucose tolerance is normal; the disorder is transmitted as autosomal dominant. Other conditions in which glycosuria can occur with blood glucose level remaining below 180 mgs/dl are renal tubular diseases in which there is decreased glucose reabsorption like Fanconi’s syndrome, and toxic renal tubular damage. During pregnancy, renal threshold for glucose is decreased. Therefore it is necessary to estimate blood glucose when glucose is first detected in urine.
Further reading: Tests for Detection of Glucose in Urine
Excretion of ketone bodies (acetoacetic acid, β-hydroxybutyric acid, and acetone) in urine is called as ketonuria. Ketones are breakdown products of fatty acids and their presence in urine is indicative of excessive fatty acid metabolism to provide energy.
Causes of Ketonuria
Normally ketone bodies are not detectable in the urine of healthy persons. If energy requirements cannot be met by metabolism of glucose (due to defective carbohydrate metabolism, low carbohydrate intake, or increased metabolic needs), then energy is derived from breakdown of fats. This leads to the formation of ketone bodies (Figure 826.2).
- Decreased utilization of carbohydrates:
a. Uncontrolled diabetes mellitus with ketoacidosis: In diabetes, because of poor glucose utilization, there is compensatory increased lipolysis. This causes increase in the level of free fatty acids in plasma. Degradation of free fatty acids in the liver leads to the formation of acetoacetyl CoA which then forms ketone bodies. Ketone bodies are strong acids and produce H+ ions, which are neutralized by bicarbonate ions; fall in bicarbonate (i.e. alkali) level produces ketoacidosis. Ketone bodies also increase the plasma osmolality and cause cellular dehydration. Children and young adults with type 1 diabetes are especially prone to ketoacidosis during acute illness and stress. If glycosuria is present, then test for ketone bodies must be done. If both glucose and ketone bodies are present in urine, then it indicates presence of diabetes mellitus with ketoacidosis (Box 826.4).
In some cases of diabetes, ketone bodies are increased in blood but do not appear in urine.
Presence of ketone bodies in urine may be a warning of impending ketoacidotic coma.
b. Glycogen storage disease (von Gierke’s disease)
- Decreased availability of carbohydrates in the diet:
b. Persistent vomiting in children
c. Weight reduction program (severe carbohydrate restriction with normal fat intake)
- Increased metabolic needs:
a. Fever in children
b. Severe thyrotoxicosis
d. Protein calorie malnutrition
Further reading: Tests for Detection of Ketones in Urine
BILE PIGMENT (BILIRUBIN)
Bilirubin (a breakdown product of hemoglobin) is undetectable in the urine of normal persons. Presence of bilirubin in urine is called as bilirubinuria.
There are two forms of bilirubin: conjugated and unconjugated. After its formation from hemoglobin in the reticuloendothelial system, bilirubin circulates in the blood bound to albumin. This is called as unconjugated bilirubin. Unconjugated bilirubin is not water-soluble, is bound to albumin, and cannot pass through the glomeruli; therefore it does not appear in the urine. The liver takes up unconjugated bilirubin where it combines with glucuronic acid to form bilirubin diglucuronide (conjugated bilirubin). Conjugated bilirubin is water-soluble, is filtered by the glomeruli, and therefore appears in the urine.
Detection of bilirubin in urine (along with urobilinogen) is helpful in the differential diagnosis of jaundice (Table 826.1).
|Urine test||Hemolytic jaundice||Hepatocellular jaundice||Obstructive jaundice|
In acute viral hepatitis, bilirubin appears in urine even before jaundice is clinically apparent. In a fever of unknown origin bilirubinuria suggests hepatitis.
Presence of bilirubin in urine indicates conjugated hyperbilirubinemia (obstructive or hepatocellular jaundice). This is because only conjugated bilirubin is water-soluble. Bilirubin in urine is absent in hemolytic jaundice; this is because unconjugated bilirubin is water-insoluble.
Further reading: Tests for Detection of Bilirubin in Urine
Bile salts are salts of four different types of bile acids: cholic, deoxycholic, chenodeoxycholic, and lithocholic. These bile acids combine with glycine or taurine to form complex salts or acids. Bile salts enter the small intestine through the bile and act as detergents to emulsify fat and reduce the surface tension on fat droplets so that enzymes (lipases) can breakdown the fat. In the terminal ileum, bile salts are absorbed and enter in the blood stream from where they are taken up by the liver and re-excreted in bile (enterohepatic circulation).
Further reading: Test for Detection of Bile Salts in Urine
Conjugated bilirubin excreted into the duodenum through bile is converted by bacterial action to urobilinogen in the intestine. Major part is eliminated in the feces. A portion of urobilinogen is absorbed in blood, which undergoes recycling (enterohepatic circulation); a small amount, which is not taken up by the liver, is excreted in urine. Urobilinogen is colorless; upon oxidation it is converted to urobilin, which is orange-yellow in color. Normally about 0.5-4 mg of urobilinogen is excreted in urine in 24 hours. Therefore, a small amount of urobilinogen is normally detectable in urine.
Urinary excretion of urobilinogen shows diurnal variation with highest levels in afternoon. Therefore, a 2-hour post-meal sample is preferred.
Causes of Increased Urobilinogen in Urine
- Hemolysis: Excessive destruction of red cells leads to hyperbilirubinemia and therefore increased formation of urobilinogen in the gut. Bilirubin, being of unconjugated type, does not appear in urine. Increased urobilinogen in urine without bilirubin is typical of hemolytic anemia. This also occurs in megaloblastic anemia due to premature destruction of erythroid precursors in bone marrow (ineffective erythropoiesis).
- Hemorrhage in tissues: There is increased formation of bilirubin from destruction of red cells.
Causes of Reduced Urobilinogen in Urine
- Obstructive jaundice: In biliary tract obstruction, delivery of bilirubin to the intestine is restricted and very little or no urobilinogen is formed. This causes stools to become clay-colored.
- Reduction of intestinal bacterial flora: This prevents conversion of bilirubin to urobilinogen in the intestine. It is observed in neonates and following antibiotic treatment.
Testing of urine for both bilirubin and urobilinogen can provide helpful information in a case of jaundice (Table 826.1).
Further reading: Tests for Detection of Urobilinogen in Urine
The presence of abnormal number of intact red blood cells in urine is called as hematuria. It implies presence of a bleeding lesion in the urinary tract. Bleeding in urine may be noted macroscopically or with naked eye (gross hematuria). If bleeding is noted only by microscopic examination or by chemical tests, then it is called as occult, microscopic or hidden hematuria.
Causes of Hematuria
1. Diseases of urinary tract:
- Glomerular diseases: Glomerulonephritis, Berger’s disease, lupus nephritis, Henoch-Schonlein purpura
- Nonglomerular diseases: Calculus, tumor, infection, tuberculosis, pyelonephritis, hydronephrosis, polycystic kidney disease, trauma, after strenuous physical exercise, diseases of prostate (benign hyperplasia of prostate, carcinoma of prostate).
2. Hematological conditions:
Coagulation disorders, sickle cell disease Presence of red cell casts and proteinuria along with hematuria suggests glomerular cause of hematuria.
Further reading: Tests for Detection of Blood in Urine
Presence of free hemoglobin in urine is called as hemoglobinuria.
Causes of Hemoglobinuria
- Hematuria with subsequent lysis of red blood cells in the urine of low specific gravity.
- Intravascular hemolysis: Hemoglobin will appear in the urine when haptoglobin (to which hemoglobin binds in plasma) is completely saturated with hemoglobin. Intravascular hemolysis occurs in infections (severe falciparum malaria, clostridial infection, E. coli septicemia), trauma to red cells (march hemoglobinuria, extensive burns, prosthetic heart valves), glucose-6-phosphate dehydrogenase deficiency following exposure to oxidant drugs, immune hemolysis (mismatched blood transfusion, paroxysmal cold hemoglobinuria), paroxysmal nocturnal hemoglobinuria, hemolytic uremic syndrome, and disseminated intravascular coagulation.
Tests for Detection of Hemoglobinuria
Tests for detection of hemoglobinuria are benzidine test, ortho-toluidine test, and reagent strip test.
Hemosiderin in urine (hemosiderinuria) indicates presence of free hemoglobin in plasma. Hemosiderin appears as blue granules when urine sediment is stained with Prussian blue stain (Figure 826.3). Granules are located inside tubular epithelial cells or may be free if cells have disintegrated. Hemosiderinuria is seen in intravascular hemolysis.
Myoglobin is a protein present in striated muscle (skeletal and cardiac) which binds oxygen. Causes of myoglobinuria include injury to skeletal or cardiac muscle, e.g. crush injury, myocardial infarction, dermatomyositis, severe electric shock, and thermal burns.
Chemical tests used for detection of blood or hemoglobin also give a positive reaction with myoglobin (as both hemoglobin and myoglobin have peroxidase activity). Ammonium sulfate solubility test is used as a screening test for myoglobinuria (Myoglobin is soluble in 80% saturated solution of ammonium sulfate, while hemoglobin is insoluble and is precipitated. A positive chemical test for blood done on supernatant indicates myoglobinuria).
Distinction between hematuria, hemoglobinuria, and myoglobinuria is shown in Table 826.2
|1. Urine color||Normal, smoky, red, or brown||Pink, red, or brown||Red or brown|
|2. Plasma color||Normal||Pink||Normal|
|3. Urine test based on peroxidase activity||Positive||Positive||Positive|
|4. Urine microscopy||Many red cells||Occasional red cell||Occasional red cell|
|5. Serum haptoglobin||Normal||Low||Normal|
|6. Serum creatine kinase||Normal||Normal||Markedly increased|
Chemical Tests for Significant Bacteriuria (Indirect Tests for Urinary Tract Infection)
In addition to direct microscopic examination of urine sample, chemical tests are commercially available in a reagent strip format that can detect significant bacteriuria: nitrite test and leucocyte esterase test. These tests are helpful at places where urine microscopy is not available. If these tests are positive, urine culture is indicated.
1. Nitrite test: Nitrites are not present in normal urine; ingested nitrites are converted to nitrate and excreted in urine. If gram-negative bacteria (e.g. E.coli, Salmonella, Proteus, Klebsiella, etc.) are present in urine, they will reduce the nitrates to nitrites through the action of bacterial enzyme nitrate reductase. Nitrites are then detected in urine by reagent strip tests. As E. coli is the commonest organism causing urinary tract infection, this test is helpful as a screening test for urinary tract infection.
Some organisms like Staphylococci or Pseudomonas do not reduce nitrate to nitrite and therefore in such infections nitrite test is negative. Also, urine must be retained in the bladder for minimum of 4 hours for conversion of nitrate to nitrite to occur; therefore, fresh early morning specimen is preferred. Sufficient dietary intake of nitrate is necessary. Therefore a negative nitrite test does not necessarily indicate absence of urinary tract infection. The test detects about 70% cases of urinary tract infections.
2. Leucocyte esterase test: It detects esterase enzyme released in urine from granules of leucocytes. Thus the test is positive in pyuria. If this test is positive, urine culture should be done. The test is not sensitive to leucocytes < 5/HPF.
